Marine Centrifugal Pump
Built for the Demands of Shipboard Service
The marine centrifugal pump is designed for clean-fuel supply systems on dual-fuel vessels using LNG, methanol, or liquid ammonia. It handles the critical job of transferring cryogenic liquid fuel from storage tanks to vaporizers or directly to the engine. The pump is engineered specifically for the constraints of shipboard installation-limited space, continuous motion, rolling and pitching conditions, sustained vibration, and strict maritime safety requirements.
Construction for Marine Conditions
All wetted components are manufactured from high-strength stainless steel, copper alloys, and other corrosion-resistant materials validated for low-temperature and corrosive service. The pump is compact and lightweight for installation in engine rooms and other confined spaces, with reinforced structural elements to maintain performance under ship motion and vibration. Flow rates range from 0.5 m³/h up to 2,500 m³/h, with heads up to 2,600 meters.
Variable Speed Control for Load Flexibility
The pump can be supplied with a variable frequency drive, allowing flow modulation to match different engine load conditions. This capability improves vessel fuel efficiency and reduces operating costs by avoiding the inefficiencies of fixed-speed operation at partial load.
Marine Certification and Testing
The marine centrifugal pump holds CCS type approval. Each unit undergoes rigorous factory performance testing, and ship surveyor witness testing can be arranged. The product meets the requirements of IMO Tier III emission regulations for clean-fuel propulsion systems.
one-stop solution
professional team
high quality
Engineering and After-Sales Support
The engineering team has extensive experience in marine fuel supply systems. For custom-engineered pumps, lead time from technical approval to delivery is typically 24 to 32 weeks depending on specifications. After delivery, installation guidance, commissioning support, spare parts supply, and remote troubleshooting are available as specified in the contract. Assistance with classification society certification can be provided upon request..
Product Specifications
|
Parameter |
Specification |
Unit |
|
Flow Rate |
0.5 – 2,500+ |
m³/h |
|
Head Range |
2 – 2,600 |
m |
|
Media |
LNG, liquid nitrogen, liquid argon, ethylene, LPG, ethane, methanol, liquid ammonia |
- |
|
Structure |
Horizontal / vertical centrifugal, direct-coupled or VFD |
- |
|
Certification |
CCS type approval |
- |
